Key Specifications
| Model | RSC‑75/91/110/171 | Bit Type | Rib Spiral PDC Core Drill Bit |
| Borehole Diameter | 75–171 mm (Custom Sizes Available) | Matrix Material | Boronized Alloy Body with Chrome-Molybdenum Ribs |
| Cutter Structure | Reinforced PDC Cutters with Self-Sharpening Edges | Connection | API Thread / Custom Adapters for Core Barrels |
| Compatible Rigs | Geotechnical & Exploration Core Drills | Core Diameter | Ø25–65 mm (Single/Double Tube) |
| Drilling Medium | Water / Mud (Low to Medium Pressure Systems) | Certification | ISO 9001 & GB |
| Compatible Rigs | Geotechnical & Exploration Core Drills | Core Diameter | Ø25–65 mm (Single/Double Tube) |
| Drilling Medium | Water / Mud (Low to Medium Pressure Systems) | Certification | ISO 9001 & GB |
Technical Features
| Cutter Layout | Spiral rib pattern with 6 PDC cutting zones and reinforced core shielding fins | ||
| Drilling Efficiency | 30% higher mud flow, reducing blockage in high-clay zones | ||
| Service Life | 250–300 m lifespan in sandstone/mudstone formations | ||
| Core Recovery | ≥90% core recovery rate in fractured or broken strata | ||
| Bonding Technology | Vacuum Brazed PDC with Boron Surface Treatment on Spiral Ribs | ||
Field Performance
- Ordos Basin Survey: Core recovery improved from 68% to 92% in sandy mudstone with RSC‑100
- Southwest China Hydropower Site: RSC‑75 drilled 80 m continuously without mud clogging
- Xinjiang Uranium Prospecting: RSC‑150 extended lifespan by 35% vs conventional bits in fractured sandstone
